Training and saving models with CML on a dedicated AWS EC2 runner (part 2)

We can use CML to automatically retrain models whenever data, model code, or parameters change. In this guide we show how to create a pipeline that provisions an AWS EC2 instance to retrain a model and save the output on a regular basis. In this part 2 we cover how to export the model to a DVC remote on Google Drive.

  • Rob de Wit
  • May 06, 20227 min read
Hero Picture

In part 1 of this guide we showed how you can use CML to provision an AWS EC2 instance to train your model before saving the model to our Git repository. In doing so, we allowed ourselves to terminate the training instance without losing our model altogether.

This worked perfectly fine for the simple model we trained, but this approach is not optimal when dealing with larger models. GitHub starts warning you at 50MB files and simply won't upload anything over 100MB. GitLab similarly limits the size of files you can store in your repository. A beefy XGBoost model can easily exceed 100MB and a neural network can go up into the gigabytes.

That means we cannot save these models directly to our repository. Luckily we can look towards another one of Iterative's open-source tools: DVC. DVC includes a lot of features for managing machine learning projects, such as ML pipelines, experiment tracking, and data versioning. In this guide we will zoom in on just one of those features: remote storage.

We can use DVC to save our model to a remote storage location, such as M3, HDFS, an SFTP server, or even Google Drive. Much like Git tracks changes to your code, DVC tracks changes to your data. It puts a reference to a specific version of your data in the Git commit. That way your code is linked to a specific version of your model, without containing the actual model.

In this part 2, we will show you how to save the model we trained in part 1 to a DVC remote. At the end of this guide our CML workflow will be doing the folowing on a daily basis:

  1. Provision an Amazon Web Services (AWS) EC2 instance
  2. Train the model
  3. Save the model to a DVC remote storage on Google Drive
  4. Save the model metrics to a GitHub repository
  5. Create a merge request with the new outputs
  6. Terminate the AWS EC2 instance

All files needed for this guide can be found in this repository.

We will be using Google Drive as our remote storage. With slight modifications, however, you can also use other remotes such as AWS S3, GCP Cloud Storage, and Azure Storage. Please refer to the DVC Docs for more details.

Prerequisites

Make sure to have followed part 1 of this guide and have gotten CML up and running. The necessary files for all of this can be found in this repository. Additionally, set up the following things beforehand:

Setting up our DVC remote

When first using DVC in a project, you need to initialize DVC by running dvc init. This will create the structure DVC uses to keep track of versioning, and ensures Git will not be tracking the files in the DVC repository. Instead, Git will henceforth include a list of references to those files. Make sure to commit the initialization to Git.

Then, in order to start using DVC for versioning, we need to set up a remote. This is where our model files will end up, while DVC keeps track of their respective versions. Here we will be using Google Drive as our remote.

The DVC user guide explains how to set up a remote on Google Drive. If you would rather use another remote, you can find instructions here. In that case make sure to also update the DVC dependency in requirements.txt.

While DVC doesn't require a service account to work, we do need one in the set-up we're aiming for. That's because without a service account we will need to authorize ourselves through a log-in page every time. Our self-hosted runner would get stuck on this page because we cannot authorize ourselves there.

In order to let DVC access the Google Drive folder we created from our runner, we need to add two more GitHub Actions secrets: GDRIVE_CREDENTIALS_DATA and GOOGLE_DRIVE_URI. The first one should contain the private key we downloaded when setting up our service account (i.e. the .json file). The second one should be the Drive URI to the directory we created in Google Drive (i.e. the sequence of random characters at the end of our Google Drive URL).

Export the model to a DVC remote

Now that we have set up the remote and made sure GitHub Actions has all the details needed to access the remote, we can use the workflow below. In this scenario, we train the model in the same way as in part 1, but we push it to the DVC remote. A reference to the location of this file is added to the GitHub repository (model/random_forest.joblib.dvc). The model itself is added to .gitignore and not pushed to the repository.

The other files created in train.py are still pushed to an experiment branch in GitHub. Afterwards a merge request is created.

name: CML with DVC
on: # Here we use two triggers: manually and daily at 08:00
  workflow_dispatch:
  schedule:
    - cron: '0 8 * * *'
jobs:
  deploy-runner:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v2
      - uses: iterative/setup-cml@v1
      - name: Deploy runner on EC2
        env:
          REPO_TOKEN: ${{ secrets.PERSONAL_ACCESS_TOKEN }}
          AWS_ACCESS_KEY_ID: ${{ secrets.AWS_ACCESS_KEY_ID }}
          AWS_SECRET_ACCESS_KEY: ${{ secrets.AWS_SECRET_ACCESS_KEY }}
        run: |
          cml runner \
              --cloud=aws \
              --cloud-region=eu-west \
              --cloud-type=t2.micro \
              --labels=cml-runner \
              --single
  train-model:
    needs: deploy-runner
    runs-on: [self-hosted, cml-runner]
    timeout-minutes: 120 # 2h
    steps:
      - uses: actions/checkout@v2
      - uses: actions/setup-python@v2
        with:
          python-version: '3.x'
      - uses: actions/setup-node@v3
        with:
          node-version: '16'
      - uses: iterative/setup-cml@v1
      - name: Train model
        env:
          REPO_TOKEN: ${{ secrets.PERSONAL_ACCESS_TOKEN }}
          GDRIVE_CREDENTIALS_DATA: ${{ secrets.GDRIVE_CREDENTIALS_DATA }}
        run: |
          cml ci
          pip install -r requirements.txt

          python get_data.py
          python train.py

          # Connect to your DVC remote storage and push the model to there
          dvc add model/random_forest.joblib # This automatically adds the model to your .gitignore
          dvc remote add -d -f myremote gdrive://${{ secrets.GOOGLE_DRIVE_URI }}
          dvc remote modify myremote gdrive_use_service_account true
          dvc push

          # Create pull request for the remaining files
          cml pr .

          # Create CML report
          cat model/metrics.txt > report.md
          cml publish model/confusion_matrix.png --md >> report.md
          cml send-comment --pr --update report.md

And that's it! We have broadly the same set-up as outlined in part 1 of this guide, but we no longer use our GitHub repository for storing our model. Instead, the model is now saved to Google Drive, which allows for much larger models.

In a situation where we retrain our model daily based on the most recent data, it would make sense to also use DVC to keep track of the data used in each training. We could, for example, use our runner to import our training data from a table in our database and write both the data and the model to the DVC remote. This is beyond the scope of this guide, but here you can find a repository that covers this.

While we have achieved our goal of using DVC for our model storage, there are some other DVC features we could benefit from as well. We could define a reproducible pipeline to replace our manual get_data.py and train.py tasks. Here you can find more information on how to achieve this.

Conclusions

As we saw in part 1 of this guide, we can use CML to automate a periodical retraining of our models on a self-hosted runner. We were able to save the model to our GitHub repository, but that approach has its limitations with regards to model size.

In this part 2 we worked around those limitations by saving our model to a DVC remote instead. We set up Google Drive as our remote and adapted our CML workflow to save our models there. All in all, we can now automatically (re)train models using a self-hosted runner, track different model versions in Git, and save models to a remote storage such as Google Drive for future reference.

A great extension of our CI/CD would be a deploy step to bring the latest version of our model into production. This step might be conditional on the performance of the model; we could decide to only start using it in production if it performs better than previous iterations. All of this warrants a guide of its own, however, so look out for that in the future! 😉
